1972: Panasonic NV-3082 EIAJ portapack VTR
along with the WV-3082 camera.

VINTAGE POLICE SURVEILLANCE EQUIPMENT. THIS EQUIPMENT WAS FROM AN APPLETON WISCONSIN POLICE DEPARTMENT AUCTION. ALL THE EQUIPMENT IS PANASONIC. WAS TOLD THAT EVERYTHING WORKS GOOD THE LAST TIME IT WAS USED. IT CONTAINS A VIDEO CAMERA, A PORTABLE VIDEO RECORDER, 2 CAR BATTERY CORDS AND 4 TAPES. THE MODEL NUMBER OF BOTH THE CAMERA AND OF THE RECORDER ARE WV3082. THE CAR BATTERIES CORDS ARE NUMBER NV-C28. ONE OF THE FOUR TAPES THAT COMES WITH THIS IS LABELED HOSTAGE FILM.





And... aside from the unit in the carry case above -  We found this second unit also...






PANASONIC TAPE-A-VISION REEL TO REEL VIDEO RECORDER









PANASONIC WV-3320 TELEVISION CAMERA; VINTAGE WORKING CAMERA... TV ZOOM LENS 100MM, IRIS CONTROL. COMES WITH CAMERA CONTROL UNIT (BOTTOM RIGHT) HAS WHITE BALANCE, COLOR ADJUSTMENT... HAS STANDARD 10 PIN CONNECTOR. GREAT SHAPE AND WORKS QUITE WELL. NOTICE THE UNIQUE USE OF A LAMP BASE AS A CAMERA STAND!





PANASONIC WV-V3
Professional COLOR Three Tube ½" Video Camera



About 1986 vintage.

  A Digital Cinema with a RED camera!


The WV-V3 is Ed Sharpe's Signature Camera at KKAT Internet Streaming TV. A Digital Cinema with a RED camera!
(Click Ed To watch the movie)


Click On any of the photos for a larger view!

Click this! great picture suitable for framing!







One form of charger.            Inside the battery case

Feature list.                         Case for the WV-V3.






This is the less expensive lens   &     View from the front.

Character Generator &  Plate from a PAL version (not ours)


Shot of a packed outfit...



Includes 10X, 1:14, 8~80mm lens, and B&W viewfinder, and lens hood, lens cap, camera case, original manual and set-up cards, Panasonic Tripod Plate WV-Q36, as well as a type of shoulder pad/support, CCU (Camera Control Unit) cable.  (We are Looking for a CCU  unit to match to this camera.).




PANASONIC WV-V3
Professional Three Tube ½" COLOR
Video Camera System

















Panasonic WV-VF65 Electronic Viewfinder/Monitor







Panasonic film/slide adaptor model # WV-AD15AE





Panasonic VW-V3 Centering Chart


Panasonic WV-V3 White Set Chart


Panasonic Sports Poster - 1980s


WV-RC33 Rack Mount RCU, AND the WV-AD33 Camera Adapter

The RCU works perfectly as it can control the essential camera functions which includes but not limited to:

*  Bar (full field) / camera mode switch
*  white balance
*  black balance
*  registration (center) switch
*  gain
*  cable comp
*  H / SC
*  R / B pots (manual color balancing)

It can be powered by both AC & 12v DC power.  It does come with the rack mount "ears" so you can directly mount the unit into your existing engineering rack





PANASONIC  Si VIDEO  CAMERA







 Unit has 12X ZOOM LENS  10.5 to 126mm, 1:1.6, Model No.WV-LZ12/12 there are also  Two BATTERY PACKS!




PANASONIC VIDEO CAMERA WV-555 WITH Studio Monitor.





Panasonic AG 7400 SVHS Portable Video Recorder

PANASONIC AG-7400 SVHS VCR This is a portable recorder player, it can be operated from a 12 volt power supply or  a battery or battery adapter. No power supply or battery was included with this unit. We need  batteries for this unit!


This is a compact, full featured professional portable recorder/player that plays S-VHS and VHS tapes for edit feed or display on a monitor. Has 14 pin camera input, 4 pin XLR power input, RCA Audio in/out (2 channel analog and 2 channel HiFi), mini headphone jack and audio level control, (2) audio selectors (selects analog or HiFi from camera microphone, line, or microphone inputs), 1/4" - Hi Z microphone inputs - Ch. 1 & 2





 The AG-7400 has a 14-pin camera connector, S-video input/output, and two(2) RCA adaptors for easy hookup to any camera or video device. As you can see in the pictures, this VTR has many options and level controls for any recording situation

wpe50.gif (92691 bytes) Panasonic color TV camera model # WV-3320 and 2 control units.
